RV1126 IPC38板 使用DK2.2无法跑通Demo

RV1126

NPU

  • 硬件： RV1126 IPC38板 spi nand flash256M
  • SDK： Ebaina提供的SSD 2.2

编译生成生的固件，想测试下rkmedia下的NPU Demo程序 ：rkmedia_vi_rockx_venc_rtsp_test

测试失败，提示摄像头被占用：

  1. [root@RV1126_RV1109:~]# rkmedia_vi_rockx_venc_rtsp_test
  2. media get entity by name: rkcif-lvds-subdev is null
  3. media get entity by name: rkcif-lite-lvds-subdev is null
  4. media get entity by name: stream_cif is null
  5. media get entity by name: rkcif-dvp-sof is null
  6. media get entity by name: rkisp-mpfbc-subdev is null
  7. media get entity by name: rkisp_dmapath is null
  8. media get entity by name: rockchip-mipi-dphy-rx is null
  9. media get entity by name: rkcif_dvp is null
  10. media get entity by name: rkcif_dvp is null
  11. media get entity by name: rkcif_lite_mipi_lvds is null
  12. [15:10:21.632639][CAMHW]:XCAM ERROR CamHwIsp20.cpp:990: No free isp&ispp needed by fake camera!
  13. rga_api version 1.2.6_[0] (RGA is compiling with meson base: $PRODUCT_BASE)
  14. >>>>>>>>>>>>>>> Test START <<<<<<<<<<<<<<<<<<<<<<
  15. ####Aiq xml dirpath: (null)
  17. ####hdr mode: 0
  19. ####fps: 30
  21. #bMultictx: 0
  23. #CameraIdx: 0
  25. ####data version: 29
  27. ####config dirpath: /oem/usr/share/rtsp-nn.cfg
  29. ####runtime path: /usr/lib/librknn_runtime.so
  31. ####photo dirpath: /tmp/
  33. ####limit score: 0.450000
  35. ####detect time log en: 0
  37. ####draw time log en: 0
  39. ####stress_mode: 0
  41. rtsp path = /live/main_stream.
  42. video_type = 7.
  43. width = 720.
  44. height = 576.
  45. video path =rkispp_scale1.
  46. image type = 4.
  47. rtsp path = /live/sub_stream.
  48. video_type = 7.
  49. width = 1920.
  50. height = 1080.
  51. video path =rkispp_scale0.
  52. image type = 4.
  53. init rtsp
  54. [INFO  rtsp_demo.c:281:rtsp_new_demo] rtsp server demo starting on port 554
  55. init mpi
  56. ##RKMEDIA Log level: 2
  57. [RKMEDIA][SYS][Info]:text is all=2
  58. [RKMEDIA][SYS][Info]:module is all, log_level is 2
  59. [DEBUG rtsp_demo.c:481:rtsp_new_session] add session path: /live/main_stream
  60. VI create
  61. [RKMEDIA][SYS][Info]:RK_MPI_VI_EnableChn: Enable VI[0:0]:rkispp_scale1, 720x576 Start...
  62. [RKMEDIA][SYS][Info]:RKAIQ: parsing /dev/media0
  63. media get entity by name: rkcif-lvds-subdev is null
  64. media get entity by name: rkcif-lite-lvds-subdev is null
  65. [RKMEDIA][SYS][Info]:RKAIQ: parsing /dev/media1
  66. media get entity by name: rkisp-mpfbc-subdev is null
  67. media get entity by name: rkisp_dmapath is null
  68. media get entity by name: rockchip-mipi-dphy-rx is null
  69. [RKMEDIA][SYS][Info]:RKAIQ: model(rkisp0): isp_info(0): isp-subdev entity name: /dev/v4l-subdev5
  70. [RKMEDIA][SYS][Info]:RKAIQ: parsing /dev/media2
  71. [RKMEDIA][SYS][Info]:RKAIQ: model(rkispp0): ispp_info(0): ispp-subdev entity name: /dev/v4l-subdev0
  72. [RKMEDIA][SYS][Info]:#V4l2Stream: camraID:0, Device:rkispp_scale1
  73. [RKMEDIA][SYS][Warn]:camera_id: 0, chn: rkispp_scale1
  74. [RKMEDIA][SYS][Warn]:camera_id: 0, chn: rkispp_scale1, idx: 0
  75. [RKMEDIA][SYS][Info]:#V4l2Stream: camera id:0, VideoNode:/dev/video20
  76. Using mplane plugin for capture
  77. [RKMEDIA][SYS][Info]:#V4L2Ctx: open /dev/video20, fd 7
  78. [RKMEDIA][SYS][Error]:rkispp_scale1, s fmt failed(cap type=1, NV12), Invalid argument
  79. [RKMEDIA][SYS][Info]:#V4L2Ctx: close , fd 7
  80. [RKMEDIA][SYS][Info]:#V4L2Stream: v4l2 ctx reset to nullptr!
  81. [RKMEDIA][VI][Info]:Create stream v4l2_capture_stream failed
  82. [RKMEDIA][VI][Info]:#SourceStreamFlow[]: stream off....
  83. [RKMEDIA][VI][Info]:#SourceStreamFlow[]: read thread exit sucessfully!
  84. [RKMEDIA][VI][Info]:#SourceStreamFlow[]: stream reset sucessfully!
  85. [RKMEDIA][SYS][Warn]:VI[0]:"rkispp_scale1" buffer may be occupied by other modules or apps, try again...
  86. [RKMEDIA][SYS][Info]:RKAIQ: parsing /dev/media0
  87. media get entity by name: rkcif-lvds-subdev is null
  88. media get entity by name: rkcif-lite-lvds-subdev is null
  89. [RKMEDIA][SYS][Info]:RKAIQ: parsing /dev/media1
  90. media get entity by name: rkisp-mpfbc-subdev is null
  91. media get entity by name: rkisp_dmapath is null
  92. media get entity by name: rockchip-mipi-dphy-rx is null
  93. [RKMEDIA][SYS][Info]:RKAIQ: model(rkisp0): isp_info(0): isp-subdev entity name: /dev/v4l-subdev5
  94. [RKMEDIA][SYS][Info]:RKAIQ: parsing /dev/media2
  95. [RKMEDIA][SYS][Info]:RKAIQ: model(rkispp0): ispp_info(0): ispp-subdev entity name: /dev/v4l-subdev0
  96. [RKMEDIA][SYS][Info]:#V4l2Stream: camraID:0, Device:rkispp_scale1
  97. [RKMEDIA][SYS][Warn]:camera_id: 0, chn: rkispp_scale1
  98. [RKMEDIA][SYS][Warn]:camera_id: 0, chn: rkispp_scale1, idx: 0
  99. [RKMEDIA][SYS][Info]:#V4l2Stream: camera id:0, VideoNode:/dev/video20
  100. Using mplane plugin for capture
  101. [RKMEDIA][SYS][Info]:#V4L2Ctx: open /dev/video20, fd 7
  102. [RKMEDIA][SYS][Error]:rkispp_scale1, s fmt failed(cap type=1, NV12), Invalid argument
  103. [RKMEDIA][SYS][Info]:#V4L2Ctx: close , fd 7
  104. [RKMEDIA][SYS][Info]:#V4L2Stream: v4l2 ctx reset to nullptr!
  105. [RKMEDIA][VI][Info]:Create stream v4l2_capture_stream failed
  106. [RKMEDIA][VI][Info]:#SourceStreamFlow[]: stream off....
  107. [RKMEDIA][VI][Info]:#SourceStreamFlow[]: read thread exit sucessfully!
  108. [RKMEDIA][VI][Info]:#SourceStreamFlow[]: stream reset sucessfully!
  109. [RKMEDIA][SYS][Warn]:VI[0]:"rkispp_scale1" buffer may be occupied by other modules or apps, try again...
  110. [RKMEDIA][SYS][Info]:RKAIQ: parsing /dev/media0
  111. media get entity by name: rkcif-lvds-subdev is null
  112. media get entity by name: rkcif-lite-lvds-subdev is null
  113. [RKMEDIA][SYS][Info]:RKAIQ: parsing /dev/media1
  114. media get entity by name: rkisp-mpfbc-subdev is null
  115. media get entity by name: rkisp_dmapath is null
  116. media get entity by name: rockchip-mipi-dphy-rx is null
  117. [RKMEDIA][SYS][Info]:RKAIQ: model(rkisp0): isp_info(0): isp-subdev entity name: /dev/v4l-subdev5
  118. [RKMEDIA][SYS][Info]:RKAIQ: parsing /dev/media2
  119. [RKMEDIA][SYS][Info]:RKAIQ: model(rkispp0): ispp_info(0): ispp-subdev entity name: /dev/v4l-subdev0
  120. [RKMEDIA][SYS][Info]:#V4l2Stream: camraID:0, Device:rkispp_scale1
  121. [RKMEDIA][SYS][Warn]:camera_id: 0, chn: rkispp_scale1
  122. [RKMEDIA][SYS][Warn]:camera_id: 0, chn: rkispp_scale1, idx: 0
  123. [RKMEDIA][SYS][Info]:#V4l2Stream: camera id:0, VideoNode:/dev/video20
  124. Using mplane plugin for capture
  125. [RKMEDIA][SYS][Info]:#V4L2Ctx: open /dev/video20, fd 7
  126. [RKMEDIA][SYS][Error]:rkispp_scale1, s fmt failed(cap type=1, NV12), Invalid argument
  127. [RKMEDIA][SYS][Info]:#V4L2Ctx: close , fd 7
  128. [RKMEDIA][SYS][Info]:#V4L2Stream: v4l2 ctx reset to nullptr!
  129. [RKMEDIA][VI][Info]:Create stream v4l2_capture_stream failed
  130. [RKMEDIA][VI][Info]:#SourceStreamFlow[]: stream off....
  131. [RKMEDIA][VI][Info]:#SourceStreamFlow[]: read thread exit sucessfully!
  132. [RKMEDIA][VI][Info]:#SourceStreamFlow[]: stream reset sucessfully!
  133. [RKMEDIA][SYS][Warn]:VI[0]:"rkispp_scale1" buffer may be occupied by other modules or apps, try again...
  134. vi start fail, ret is -11, order is 0

通过PS查，未发现，有占用信息，不知哪里被占用，求解~
